Model: KF-LF5A
-
Voltage: 415V / 50Hz / 3Ph
-
Normal Temperature Range: 3℃ – 35℃ (below 0℃ can be customized)
Input Power
-
KW: 6
Cooling Capacity
-
KW: 13.05
-
Kcal/h: 11223
Compressor
-
Type: Hermetic scroll type
-
Power: 5 HP
-
Number: 1
Condenser
-
Type: Efficient microchannel aluminum heat dissipation + low noise outer rotor fan
-
Air Volume: 5000 m³/h
Evaporator
-
Type: Shell tube / Tank coil
-
Cooling Water: 2.24 m³/h
-
Inlet and Outlet Pipe Diameter: DN25, 1"
Refrigerant
-
Type: R410A
-
Control Mode: Outside the balanced thermal expansion valve
Water Pump
-
Power: 0.75 KW
-
Flow: 123 L/min
-
Lift: 22 m
Dimension
-
Size: 149 × 72 × 115 cm
Weight
-
200 KG
